Description
-
FrameFORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-2™ Adjustable Geometry | 130mm Travel. FORM™ Alloy Rear Triangle
-
ForkRockShox Reba R 140mm | 40m Offset
-
ShockRockShox Deluxe Select | Sealed Bearing Eyelet | 20x8mm F Hardware | 170x35mm
-
Rear Travel130
-
HeadsetFSA ZS56|66 Reach Adjust| 5mm Cups Installed | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
-
StemRocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm
-
HandlebarRocky Montain Jr | 640mm Width |25mm rise | 9° Backsweep |5° Upsweep | 31.8 | For 19mm Grips
-
GripsSGD Slater JR Lock On
-
BrakesTektro HD-J285 | Short Reach Lever | Shimano Pad Compatible
-
ShiftersShimano CUES 10spd
-
Rear DerailleurShimano CUES 10spd
-
Cranks & ChainringRocky Mountain Microdrive 2PC | 30T | SRAM Direct Mount | 24mm Spindle | Crank Length: 155mm
-
Bottom BracketRocky Mountain Sealed - Shimano Compatible
-
CassetteShimano CUES 11-48T 10spd
-
ChainKMC X11-1
-
Front HubShimano TC500 | 15x100m | 28H
-
Rear HubShimano TC500 Boost 148mm | 28H
-
Spokes2.0 Stainless
-
RimsWTB ST Light i27 TCS 2.0 Tubeless | 28H / Tubeless Ready - Tape / Valves Incl
-
TiresF: Maxxis Minion DHF 2.4 WT EXO Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready //
-
SeatpostX Fusion Manic Composite 30.9mm | 125mm
-
SaddleRocky Mountain Kids
-
Drive SystemDyname S4 Mini Mountain Bike Drive | 300W Max Power | 250W Nominal Power | 40Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada
-
Battery240 Wh Fully Integrated Li-Ion
-
RemoteRocky Mountain Micro Remote
-
DisplayRocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration
-
ChargerRocky Mountain Powerplay Charger V2 | 2A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4)
-
WeightThis information isn't available yet. We will update the weight of this model as soon as possible.
-
NotesWe make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification.
