Description
Frameset
- Frame
- Notch Aluminum
- Fork
- RockShox Domain Gold RC, 170mm
- Rear Shock
- Fox Float X Performance Series
- Color
- Silver
Drivetrain
- Drive Unit
- Bosch Performance Line CX - BDU37
- E-Bike Classification
- Class 1
- Drive Type
- Mid-drive
- Max Assist Speed
- 20mph
- Motor Torque
- 85Nm
- Range Estimate
- 60 miles
- Assist Levels
- Eco, Tour, eMTB, Turbo (Bosch smart system offers programable mode settings in the eBike Flow app)
- Walk Assist
- Yes
- Max Motor Assist
- 340% up to 600 watts
- Throttle
- No
- Battery Capacity Watt Hours
- 500Wh
- Battery Capacity Amp Hours
- 13.4Ah
- Battery Power Volts
- 36V
- Battery Type
- Li-Ion (PowerTube 500)
- Removable Battery
- Removable for service
- Estimated Charge Time
- 4.5 hours
- Charger Included
- Yes
- Lights Included
- No
- Front Derailleur
- N/A
- Rear Derailleur
- Shimano Deore M6100-SGS
- Cassette
- Shimano Deore M6100-12, 10–51t, 12-speed
- Chain
- Shimano Deore M6100 HYPERGLIDE+
- Crankset
- FSA CK-762 w/ RaceFace direct-mount chainring, 34t. MRP 1x SL TR2 for Bosch Performance Line CX BDU37
- Shifter
- Shimano Deore M6100
- Brake Levers
- Shimano Deore M6100
- Brake Caliper
- Shimano Deore M6120, 4-piston
- Rotors
- Shimano Deore RT64, Center Lock (220mm front and rear)
Components
- Headset
- ACROS AZX-721 ZS56/ZS66 for 1.8" tapered steerer
- Stem
- Salsa Guide 40mm
- Handlebar
- RaceFace Chester, 780mm wide, 20mm rise
- Grips/Bar Tape
- WTB Wavelength
- Seatpost
- Tranz X YSP18, SM: 150mm travel; MD, LG, XL: 170mm travel
- Saddle
- WTB Solano, Medium, Fusion Form, steel rail
Wheels
- Front Hub
- Shimano TC500-15-B, 32h
- Rear Hub
- Shimano TC500-MS-B, 32h
- Spoke
- 2.0 mm straight gauge, black
- Rim
- WTB ST i30 Tough, TCS
- Front Tire
- Teravail Kessel 29 x 2.6", Ultra Durable casing, WTB TCS Sealant included (tubes installed)
- Rear Tire
- Teravail Warwick 29 x 2.5", Ultra Durable casing, WTB TCS Sealant included (tubes installed)
Weight
- Complete Bike Weight
- 59 lbs 0 oz (Medium)
