35mm chassis with a focused all-mountain mindset - satisfyingly stiff, efficient and designed to eliminate as much weight as possible.
ButterCups block 20% of high frequency “trail chatter”. Limiting these vibrations massively reduces hand and arm fatigue leaving you feeling fresh with more control.
Charger 3 features a new Internal Floating Piston (IFP) design with better fidelity, performance and truly independent adjustments without any "cross talk".
DebonAir+ is built to balance butter-like small bump feel, increased air volume, and higher overall ride height
Ultimate Bushing Package maximizes the fork’s bushing overlap, reducing friction and creating the smoothest ride possible
Pressure Relief Valves eliminate unwanted air pressure build up in the lower leg caused by variations in altitude or temperature.
RockShox premium short fender included
SRAM Model ID: FS-LYRK-ULT-D1
| Axle/Hub spacing |
15x110mm TA |
| Crown Material |
Aluminum |
| Maximum Tire Width |
81mm |
| Primary Color |
Black |
| Steerer Tube |
1-1/8-1.5 |
| Brake Type |
Disc |
| Damping Adjustments |
Extl begin stroke rebnd low speed comp high speed comp |
| Steerer Tube Material |
Aluminum |
| Stanchions Material |
Aluminum |
| Travel |
140mm |
| Damping |
Charger 3 RC2 |
| Rake |
37mm |
| Stanchions Diameter |
35mm |
| Maximum Rotor Size |
220mm |
| Spring Type |
DebonAir+ |
| Wheel Diameter |
27.5 |
| Lower Tubes Material |
Magnesium |
| Spring Adjustments |
Air pressure Bottomless tokens |
