Rims: WTB CZR i30 Carbon 29"
ETRTO 622-30
Inner width: 30mm
Torayca T700 UD carbon fiber for stiffness and compliance
Asymetric and angled spoke hole drilling
Externally reinforced spoke bed
Drilled for Presta valve
TCS 2.0 Tubeless System compatible
Solid Strip (incl.)
32 holes
Front hub: Shimano XT HB-M8110-B Boost
15x110mm (Axle not incl.)
Center Lock (6-Bolt adapter incl.)
Polished angular contact bearings
Contact sealed hub
Rear hubs options: Shimano XT FH-M8010-B (Boost, HG) / FH-M8110-B (Boost, MS) / FH-M8130-B (SuperBoost, MS)
Center Lock (6-Bolt adapter incl.)
Quick Engagement Freehub, 36 Points, 10 deg. engagement
HG compatible Shimano 11spd and Sram NX / SX splined 12spd (10spd and below needs spacer)
MS compatible 12 Spd Shimano Micro Spline only
Sold in Pair, including:
Tubeless Valve (x2)
Assembled in North-America by experienced wheelbuilders with Sapim Race spokes (Black), Polyax Nipples (Black)
| Rim inner width range |
28-34.9mm |
| Rim Material |
Carbon |
| Skewers Included |
No |
| Hub Spacing |
F: 110 R: 148 |
| Rim Internal Width |
30mm |
| Freehub Body |
Shimano HG |
| Wheel Diameter/ISO |
29 / 622 |
| Axle Type |
F: 15mm R: 12mm |
| Rim Construction |
Double wall |
| Rim Drilling |
32 |
| Valve |
Presta |
| Hub Model |
Shimano XT HB-M8110-B / FH-M8010-B |
| Wheel Weight |
1965g (pair) |
| Wheel-Brake Comp. |
Disc Center Lock / IS 6-Bolt |
| Position |
Front and Rear |
| Rim Color |
Black |
| Rim Model |
WTB CZR i30 |
| Spoke Type |
Sapim Race |
| Wheel Tire Type |
Tubeless Compatible |
